2024 NEW DESIGN & FEATURES

Product Video  click to view

Dimensions (cm) 590 x 230 590 x 230
Swim Power & Depth 1.3m 1.5m
PRO:           6 hp. 2 Swim Jets.            1,200 Lpm £31,995 £32,995
PRO PLUS: 9 hp. 3 Swim Jets.  1,800 Lpm £32,995 £33,995
EXTREME: 12 hp. 4 Swim Jets. 2,400 Lpm £33,995 £34,995

All prices include 20% VAT

HIDDEN
Spa End Specs
Spa End
Seating for 6 Lounger + 5 Seats
Massage Jets in spa end 64
Pumps 1 x 2.5 hp + Circ. Pump
Air Aromatherapy System 1,000 w
Heater 3 kW

Priced Options & Delivery Prices
Factory Fitted Options
Bluetooth Audio System +£800 each end
Arctic Insulation Upgrade +£900
WiFi Remote Control via App on phone +£550 each end
Cover Options:
Clear Lift Automatic Cover (fitted) +£7,490
Covana™ Legend +£17,495
Roll-A-Way Cover +£4,599
Heating Option:
Air Source Heat Pump (fitted) 5.5 kW: +£2,450 each end
Construction Options:
Electrical connection +£POA
Groundworks /  Concrete Base +£POA
Delivery Options:
Hiab Delivery Lorry +£1,500*
Mobile Crane +£2,500*
*Crane & Hiab Prices Subject to Site Visit & Quotation

Product Images  click to expand



Click To View PDF Brochure

Quick Specification

There is no doubt that the Vortex Hydrozone™ gives you the best of both worlds, combining two completely separate zones to create the multifunctional Hydrozone™ swim spa. At one end you can luxuriate in Vortex’s hydrotherapy-focused spa pool, and at the other enjoy exercise and family fun in the spacious swim spa.

Prices

Dimensions 590 x 230 cm 590 x 230 cm
Choose Swim Power & Depth 1.3m Deep 1.5m Deep
PRO: 6 hp. 2 Swim Jets.            1,200 Lpm £31,995 £32,995
PRO PLUS: 9 hp. 3 Swim Jets.  1,800 Lpm £32,995 £33,995
EXTREME: 12 hp. 4 Swim Jets. 2,400 Lpm £33,995 £34,995

All prices include 20% VAT

HIDDEN
Spa End Specs
Spa End
Seating for 6 Lounger + 5 Seats
Massage Jets in spa end 64
Pumps 1 x 2.5 hp + Circ. Pump
Air Aromatherapy System 1,000 w
Heater 3 kW

Priced Options & Delivery Prices
Factory Fitted Options
Bluetooth Audio System +£800 each end
Arctic Insulation Upgrade +£900
WiFi Remote Control via App on phone +£550 each end
Cover Options:
Clear Lift Automatic Cover (fitted) +£7,490
Covana™ Legend +£17,495
Roll-A-Way Cover +£4,599
Heating Option:
Air Source Heat Pump (fitted) 5.5 kW: +£2,450 each end
Construction Options:
Electrical connection +£POA
Groundworks /  Concrete Base +£POA
Delivery Options:
Hiab Delivery Lorry +£1,500*
Mobile Crane +£2,500*
*Crane & Hiab Prices Subject to Site Visit & Quotation

Key Features

  Controls – SpaNet™ Touch Screen ■  Cabinet LED Lighting
  Perimeter & Dual Layer Insulation ■  Backlit Drink Holders
■  Thermobond, 4 Layer Shell ■  Hydroglow LED Jet Lighting
■  Maintenance-Free Cabinet ■  Hydroflow S/Steel Jets
■  Purezone Easy Clean Filters ■  LED Fountain Jets
■  Purezone Ozone Water Clarifier ■  Neck Massage Collar
■  Purezone UV Water Purifier ■  Underwater LED Lighting
■  Chlorine Free Water ■  Air Blower Aromatherapy
■  Water Cascade Feature ■  Ice Cabinet / Drinks Holder
■  Moulded, High Impact Base ■  Hard Insulating Covers
■  Great Warranty ■  Lockable Covers



Quick Specification

Dimensions:   590 x 230 x 130 cm 590 x 230 x 150 cm
    1.3 m Deep 1.5m Deep
Pool End Litres
5,425 6,000
Spa End Litres
1,260 1,300
Weight: Kg Pro Pro Plus Extreme
1.3m: Dry 1,431 1,480 1,530
1.3m: Filled 8,174 8,223 8,273
1.5m: Dry 1,500 1,531 1,580
1.5m: Filled 8,859 8,890 8,939
Pool End Electrics: 32 Amps 32 Amps 40 Amps
Spa End Electrics: 20 Amps 20 Amps 20 Amps



Choose Your Swim Power Levels:

PRO►►   PRO PLUS►►   EXTREME►►►►





PRO►►

2 x Swim Jets

2 x 3hp Pumps

Total: 6hp

Swim Flow Rate: 1,200 Lpm




PRO PLUS ►►►

3 x Swim Jets

3 x 3hp Pumps

Total: 9hp

Swim Flow Rate: 1,800 Lpm




EXTREME ►►►►

4 x Swim Jets

4 x 3hp Pumps

Total: 12hp

Swim Flow Rate: 2,400 Lpm



New & Exclusive

ClearLift™ Automatic Cover

Details

ClearLift™ is an automatic motorised system that opens and closes your swim spa cover at the turn of a key. It consists of a cover and frame that are attached to the swim spa and the key controller.

As a priced option when ordering the ClearLift™ you can select the LEFT or RIGHT side for the cover to fold into.

Requires an 80 cm gap on the chosen side.



IMPORTANT:

ClearLift™ can only be fitted at the time of manufacturer. You cannot buy it separately and fit it at a later date. You can not install it on a previously purchased Vortex™ swim spa.

ClearLift™ is an optional motorised system that opens and closes your swim spa cover at the turn of a key.

It cannot be retrofitted.

Installation Examples

This is a great resource as it’s packed with lots of great ideas on how you could install a swimspa in your garden. If you have any questions please contact us.

AquaGym Max ProPlus 1.5m On Display

AquaGym Max 1.5m ProPlus Ex-display

FREE Private Swim Test Available

When you are considering purchasing a high-value product it is essential to make sure the swim matches your performance level.  Also to evaluate the hydro-massage, space and other features.



Air Source Heat Pump Option:



Reduce Heating Costs by up to 60%.



Energy Efficiency Options.

Vortex swimspas are quality built and energy efficient.  However, with the recent increase in energy costs, we can offer you an alternative heating solution to dramatically reduce your energy consumption.

Standard:

Efficient & Affordable

Electric Heater: 2 x 3kW

RUNNING COST: APPROX: £118 / month* each end



Optional:

Reduce Heating Costs by up to 60%

SpaNet Integrated Heat Pump: 5.5 kW

RUNNING COST APPROX: £48 / month*



Air Source Heat Pump

DETAILS

The forecasted running cost is an average over the 12 months of the year. Therefore, it will be lower in summer and higher in winter but average out across the year. Based on the 2 in-line 3kW heater that comes as standard with this model. For more information on what the heating cost is based on, please scroll down to the bottom of this page.





DETAILS

The standard electric spa water heater turns 2 kilowatts of electricity into 2 kilowatts of heat. The Air Source Heat Pump uses 2 kilowatts of electricity to capture 6 kilowatts of solar heat energy, giving you up to 4 kilowatts of heat for free! Overall heating costs will be significantly reduced by up to 60%. The heat pump can also refrigerate (Chill) your water if you want it to cool down quickly in hot weather.













































Related Search Categories  click to view

Contact us today

Email us your questions 🙂

Need help deciding?

We are here to help

Vortex Swimspa - Design Ideas

This video is a great free resource for swim spa design ideas. It’s packed with lots of great ideas you could use in your location and shows the whole process from start to finish.



What Power Supply Will I Need?

The Vortex Hydrozone is configured to require two separate power supplies. One supply for the end of the spa and one supply for the pool end. Therefore, you will require a qualified electrician to connect the swim spa to 2 RCD protected standalone supplies. Each with its own isolation switch.

Spa End:  20 Amp supply.

Pool End:  Pro & ProPlus are 32 amp. The Extreme model is 40 Amp.



Heating Details

We forecast an average electrical running cost of approximately £118 per month, which is an average over the 12 months of the year. Therefore, it will be less during the summer and higher over the winter, but it will average out across the year.

Based upon (as of July 2023 and subject to change):

  • 34p / kW / h
  • 1 water change per year
  • 33°C water temperature all year round
  • Cover on when not in use
  • Usage > Ave. 3 x 20-minute sessions per week

Finance Details:

Credit is subject to status and affordability.  Terms and conditions apply.  Oyster Pools & Hot Tubs Ltd, Raglan Garden Centre, Raglan, Usk. NP15 2BH.  (FCA Register No 704291). Trading as Oyster Pools & Hot Tubs Ltd is a credit broker and not the lender and is authorised and regulated by the Financial Conduct Authority. Credit is provided by Novuna Personal Finance, a trading style of Mitsubishi HC Capital UK PLC. Authorised and regulated by the Financial Conduct Authority.







Additional Information

Fully reclined lounger

This model features a reclined lounger. This allows for total body immersion for a full hydrotherapy experience.

Individual jet controls
To give you the most control over your experience, each seat has individual jet controls. This means you can set it to your own comfort level.
Multi-coloured LED lighting

The bright multi-coloured LEDs are perfect for setting the tone for your evening. Alternatively, you can put it on colour change mode for a more upbeat, party atmosphere.

Multicolour LED lighting
Built-in drinks holders

You will never be far away from your beverage as the Vortex swimspa features non-slip built-in drinks holders, so you don’t have to keep hold of your drink or climb out to take a sip.

SMARTStream Bluetooth Audio System (optional)

SMARTStream Bluetooth audio with a sub-woofer. The hidden, state of the art transducer speaker system leaves the spa surfaces clear of obstacles and reduces moving parts.

Vortex_Bluetooh_Audio
Neck and shoulder therapy collars

This Vortex model has a built-in therapy neck collar. This means that not only will your neck and shoulders be cushioned but internal jets will massage and soothe at the same time.

Laminar Jets water feature

The laminar jets smooth and uninterrupted flow of water is both relaxing and mesmerising. It’s also a ‘splash-free’ feature.

Sensual Aromatherapy System

Exclusive to our Vortex models. All you need to do is choose your favourite aromatherapy fragrances out of the 12 available and then enjoy breathing in the relaxing aroma whilst your muscles are being soothed by the powerful jets.

Opal Spas. Hydro-Sport. White Pearl + Grey
PureZone CD Ozone Water Clarifying System

This is one of the safest and most economical ways of cleaning the water as there a no harsh chemicals added to the water and the process doesn’t affect the taste, smell or PH level of the water making it child safe.

Thermabond 4 layer shell construction

All Vortex model use a 4 layer, 8 step Thermabond lamination process not found in most spas. This process includes the curing of the shell in a temperature and humidity-controlled oven. This is absolutely vital if the shell of the spa is to last the lifetime of ownership.

Dual-layer insulation

The Vortex dual layer insulation covers both the outer cabinet and the shell. This is the most efficient way to insulate. The dual layer system keeps the heat from the pumps and plumbing, reduces noise and provides a warm layer between the water and the outside of the spa.

Built To Last:

Permaframe – is a timber-free design, is impervious to rot, mildew or vermin damage and is designed to last indefinitely.

Toughbase – is built strong enough to take the weight of the swim spa, water and people. It prevents vermin from getting inside the workings of your spa and is virtually indestructible to ensure years of trouble-free usage.



Duraflex plumbing – specially designed for use in high-performance swim spas. Duraflex incorporates a coil of rigid PVC within its walls that allows the piping to flex but not kink.

Specification

Name Hydrozone Pro Hydrozone Pro Plus Hydrozone Extreme
Size (cm) 590 x 230 x 130 or 150 590 x 230 x 130 or 150 590 x 230 x 130 or 150
Spa Capacity 5 seats + Lounger 5 seats + Lounger 5 seats + Lounger
Spa Pump 2.5 hp x 1 2.5 hp x 1 2.5 hp x 1
Swim Jet Pumps 3hp x 2 3hp x 3 3hp x 4
Circulation Pump (1 Spa, 1 Pool) 250W x 2 250W x 2 250W x 2
Swim Flow Rate 1,200 Lpm 1,800 Lpm 2,400 Lpm
Total Jets (Stainless Steel) 66 (2 Swim Jets) 67 (3 Swim Jets) 68 (4 Swim Jets)
2 x Controllers SpaNet Touch Screen SpaNet Touch Screen SpaNet Touch Screen
Variable Speed Air Blower, spa 1,000W 1,000W 1,000W
Variable Output Heater (1 Spa, 1 Pool) 2 x 3kW max 2 x 3kW max 2 x 3kW max
Perimeter Insulation
Dual-layer Insulation
Intelligent Thermal Tuning
Thermobond, 4 Layer Shell Construction
Thermoclad Cabinet
Purezone Micro Filtration
Purezone Ozone Water Clarifier
Purezone UV Water Purifier
Duraflex Plumbing
Moulded, High Impact Base
Spa Health Indicator
Adjustable Aromatherapy
Water Cascade
Underwater Flood Lighting
Lockable Hard Cover
Neck Therapy Collar
Stainless Steel Jets
Backlit Laminar Jets
Hydroflow Stainless Steel Jets
Hydroglow Jet LED lighting Optional Optional Optional
Individual Seat Pressure Controls
Backlit Drink Holders
Perimeter and Cabinet Lighting
Hybrid Heat Pump Optional Optional Optional
Hydravibe Bluetooth Stereo System Optional Optional Optional
Wifi App-based Remote Control Optional Optional Optional
Arctic Pack Insulation Optional Optional Optional
Electrical (max) 15 + 15amps 15 + 32amps 15 + 40amps
Dry Weight: 1.3 & 1.5m 1,431 / 1,500 kg 1,480 / 1,531 kg 1,530 / 1,580 kg
Filled Weight: 1.3 & 1.5m 8,174 / 8,859 kg 8,223 / 8,890 kg 8,273 / 8,939 kg
Spa Water Volume:1.3 & 1.5m 1,260 / 1,300 L 1,260 / 1,300 L 1,260 / 1,300 L
Pool Water Volume:1.3 & 1.5m 5,425 / 6,000 L 5,425 / 6,000 L 5,425 / 6,000 L
Name Hydrozone Pro Hydrozone Pro Plus Hydrozone Extreme

Warranty









Warranty Hydrozone
Frame 10 years
Non Pro rata Structural 10 years
Non Pro rata Acrylic surface 5 years
Plumbing, Heater & Jet * 5 years
Pump & Equipment * 2 years

*First 12 months includes parts and labour cost. After 12 months parts only. Full written details on request.
